Description
Vigil Prox is the latest in the field of Contactless Read-only and Smart Card, MIFARE® based Modern Time Management Solutions with unparalleled features for any indoor or outdoor installation.
Features:
- Highly sensitive contactless reader ensuring cent per cent reading
- TCP/IP protocol connects directly for online data transfer
- True On-Line control, controlling the entry and exit in online mode from the PC / Central Server
- Blue Backlit Graphical display for 5 to 10 digit
- Provision for function cards, prefix and suffix numbers
- Features of Mifare programmable Smart Card Reader
- ISO 14443A programmable Smart Card Technology
- Available programmable access to all sectors.
- Input/Output ports for linking alarms, sensors, etc
Technical Specifications:
- CPU: RISC based high speed 200 MHz Micro Controller
- Memory Capacity: 1 MB Flash RAM approximately 20000 punches and 5000 employee detail.
- Blue Backlit Graphical display for card no., date, time, and status of memory consumed.
- Communication : 10BaseT (TCP/IP) all built-in
- Connect through GPRS Mobile Network to transfer data (optional)
- Built-in 5 years lithium battery backup for RAM & Real-Time Clock & Calendar
- Badge Reading: MIFARE® Contactless Smart Cards (ISO 14443 A)
- Read Range : 0-2.5 in (0-6 cm)
- Size : 180mm x 135mm x 35mm
- Enclosure: ABS Plastic IP 54
- Operating Temp : -200C to 550C
- Humidity : 0 – 95% non condensing
- Input Voltage : 12V DC 5W
- Built-in Potential free change over contact for controlling/signalling external devices
- Reading Technology: MIFARE® contactless proximity 13.56 MHZ.
